@@ -0,0 +1,144 @@
|
|
|
+<!DOCTYPE html>
|
|
|
+<html lang="en">
|
|
|
+ <head>
|
|
|
+ <title>three.js webgpu - arraycamera</title>
|
|
|
+ <meta charset="utf-8">
|
|
|
+ <meta name="viewport" content="width=device-width, user-scalable=no, minimum-scale=1.0, maximum-scale=1.0">
|
|
|
+ <link type="text/css" rel="stylesheet" href="main.css">
|
|
|
+ </head>
|
|
|
+ <body>
|
|
|
+ <script type="importmap">
|
|
|
+ {
|
|
|
+ "imports": {
|
|
|
+ "three": "../build/three.webgpu.js",
|
|
|
+ "three/webgpu": "../build/three.webgpu.js",
|
|
|
+ "three/tsl": "../build/three.tsl.js",
|
|
|
+ "three/addons/": "./jsm/"
|
|
|
+ }
|
|
|
+ }
|
|
|
+ </script>
|
|
|
+
|
|
|
+ <script type="module">
|
|
|
+
|
|
|
+ import * as THREE from 'three';
|
|
|
+
|
|
|
+ let camera, scene, renderer;
|
|
|
+ let mesh;
|
|
|
+ const AMOUNT = 6;
|
|
|
+
|
|
|
+ init();
|
|
|
+
|
|
|
+ function init() {
|
|
|
+
|
|
|
+ const ASPECT_RATIO = window.innerWidth / window.innerHeight;
|
|
|
+
|
|
|
+ const WIDTH = ( window.innerWidth / AMOUNT );
|
|
|
+ const HEIGHT = ( window.innerHeight / AMOUNT );
|
|
|
+
|
|
|
+ const cameras = [];
|
|
|
+
|
|
|
+ for ( let y = 0; y < AMOUNT; y ++ ) {
|
|
|
+
|
|
|
+ for ( let x = 0; x < AMOUNT; x ++ ) {
|
|
|
+
|
|
|
+ const subcamera = new THREE.PerspectiveCamera( 40, ASPECT_RATIO, 0.1, 10 );
|
|
|
+ subcamera.viewport = new THREE.Vector4( Math.floor( x * WIDTH ), Math.floor( y * HEIGHT ), Math.ceil( WIDTH ), Math.ceil( HEIGHT ) );
|
|
|
+ subcamera.position.x = ( x / AMOUNT ) - 0.5;
|
|
|
+ subcamera.position.y = 0.5 - ( y / AMOUNT );
|
|
|
+ subcamera.position.z = 1.5;
|
|
|
+ subcamera.position.multiplyScalar( 2 );
|
|
|
+ subcamera.lookAt( 0, 0, 0 );
|
|
|
+ subcamera.updateMatrixWorld();
|
|
|
+ cameras.push( subcamera );
|
|
|
+
|
|
|
+ }
|
|
|
+
|
|
|
+ }
|
|
|
+
|
|
|
+ camera = new THREE.ArrayCamera( cameras );
|
|
|
+ camera.position.z = 3;
|
|
|
+
|
|
|
+ scene = new THREE.Scene();
|
|
|
+
|
|
|
+ scene.add( new THREE.AmbientLight( 0x999999 ) );
|
|
|
+
|
|
|
+ const light = new THREE.DirectionalLight( 0xffffff, 3 );
|
|
|
+ light.position.set( 0.5, 0.5, 1 );
|
|
|
+ light.castShadow = true;
|
|
|
+ light.shadow.camera.zoom = 4; // tighter shadow map
|
|
|
+ scene.add( light );
|
|
|
+
|
|
|
+ const geometryBackground = new THREE.PlaneGeometry( 100, 100 );
|
|
|
+ const materialBackground = new THREE.MeshPhongMaterial( { color: 0x000066 } );
|
|
|
+
|
|
|
+ const background = new THREE.Mesh( geometryBackground, materialBackground );
|
|
|
+ background.receiveShadow = true;
|
|
|
+ background.position.set( 0, 0, - 1 );
|
|
|
+ scene.add( background );
|
|
|
+
|
|
|
+ const geometryCylinder = new THREE.CylinderGeometry( 0.5, 0.5, 1, 32 );
|
|
|
+ const materialCylinder = new THREE.MeshPhongMaterial( { color: 0xff0000 } );
|
|
|
+
|
|
|
+ mesh = new THREE.Mesh( geometryCylinder, materialCylinder );
|
|
|
+ mesh.castShadow = true;
|
|
|
+ mesh.receiveShadow = true;
|
|
|
+ scene.add( mesh );
|
|
|
+
|
|
|
+ renderer = new THREE.WebGPURenderer();
|
|
|
+ renderer.setPixelRatio( window.devicePixelRatio );
|
|
|
+ renderer.setSize( window.innerWidth, window.innerHeight );
|
|
|
+ renderer.setAnimationLoop( animate );
|
|
|
+ renderer.shadowMap.enabled = true;
|
|
|
+ document.body.appendChild( renderer.domElement );
|
|
|
+
|
|
|
+ //
|
|
|
+
|
|
|
+ window.addEventListener( 'resize', onWindowResize );
|
|
|
+
|
|
|
+ }
|
|
|
+
|
|
|
+ function onWindowResize() {
|
|
|
+
|
|
|
+ const ASPECT_RATIO = window.innerWidth / window.innerHeight;
|
|
|
+ const WIDTH = ( window.innerWidth / AMOUNT );
|
|
|
+ const HEIGHT = ( window.innerHeight / AMOUNT );
|
|
|
+
|
|
|
+ camera.aspect = ASPECT_RATIO;
|
|
|
+ camera.updateProjectionMatrix();
|
|
|
+
|
|
|
+ for ( let y = 0; y < AMOUNT; y ++ ) {
|
|
|
+
|
|
|
+ for ( let x = 0; x < AMOUNT; x ++ ) {
|
|
|
+
|
|
|
+ const subcamera = camera.cameras[ AMOUNT * y + x ];
|
|
|
+
|
|
|
+ subcamera.viewport.set(
|
|
|
+ Math.floor( x * WIDTH ),
|
|
|
+ Math.floor( y * HEIGHT ),
|
|
|
+ Math.ceil( WIDTH ),
|
|
|
+ Math.ceil( HEIGHT ) );
|
|
|
+
|
|
|
+ subcamera.aspect = ASPECT_RATIO;
|
|
|
+ subcamera.updateProjectionMatrix();
|
|
|
+
|
|
|
+ }
|
|
|
+
|
|
|
+ }
|
|
|
+
|
|
|
+ renderer.setSize( window.innerWidth, window.innerHeight );
|
|
|
+
|
|
|
+ }
|
|
|
+
|
|
|
+ function animate() {
|
|
|
+
|
|
|
+ mesh.rotation.x += 0.005;
|
|
|
+ mesh.rotation.z += 0.01;
|
|
|
+
|
|
|
+ renderer.render( scene, camera );
|
|
|
+
|
|
|
+ }
|
|
|
+
|
|
|
+ </script>
|
|
|
+
|
|
|
+ </body>
|
|
|
+</html>
|
